High School Technology Education Program in Grantsburg, WI

Annual service for a Grantsburg school woodworking shop included repairs to its C-Aire 7.5 HP 80 gallon compressor's sight glass, high-pressure jug gasket, suction valve, drains, and regulator.

Industry
Woodworking Shops for High School Technology Education Program
Service Type
Yearly Preventative Maintenance
Equipment
C-Aire 7.5 HP 80 Gal Vertical Air Compressor (Fully Packaged)
C-Aire 7.5 HP 80 Gal Vertical Air Compressor (Fully Packaged) installed at High School Technology Education Program in Grantsburg, WI

The problem

The school needed air for woodworking tools, spray finishing, and general shop use within its annual maintenance budget. Inspection found leaks at the sight glass, high-pressure jug gasket, float drains, and pressure switch. A worn suction valve, faulty moisture minder drain hose, and failing regulator also needed attention.

The work

We changed the oil, oil filters, air filters, inline filters, and filter desiccant. Repairs addressed the sight glass, jug gasket, pressure switch, drain hose, and regulator; the suction valve and float drains were replaced. We inspected belts and electrical components, cleaned the breather and cooler, and tested the drains.

Services Performed

  • Changed oil
  • Changed oil filters
  • Changed air filters
  • Changed inline filters
  • Repaired sight glass leak
  • Repaired high-pressure jug gasket leak
  • Installed new suction valve
  • Inspected belts and drains
  • Repaired moisture minder drain hose
  • Changed desiccant on filter
  • Inspected electrical components
  • Repaired air leak from pressure switch
  • Blew out cooler and unit
  • Cleaned breather
  • Tested drain
  • Replaced float drains
  • Repaired regulator

The outcome

All issues resolved in a single service visit. Safe, reliable compressed air restored for the school shop program with predictable annual maintenance costs that fit the school budget.
